‘X’ Series Products

60 GHz Outdoor Wireless Broadband Solutions

The Peraso ‘X’ Series Products provide multi-gigabit per second throughput and operate across the industrial -40°C to 85°C temperature range. They incorporate high-speed USB 3.0 system interface to integrate with common low-cost network processor ICs.

The Peraso ‘X’ Series Products operate in the 60 GHz V-band spectrum to enable rapid, license-free deployment in most major geographic markets. The 60 GHz band offers a large contiguous operating band to deliver multi gigabit per second throughput, and is particularly well suited to avoid the increasing interference problems suffered by traditional 2.4 GHz and 5 GHz WiFi bands.

The Peraso X710 Chipset

The Peraso X710 chipset includes the PRS1151 direct conversion 60 GHz RFIC and the PRS4601 baseband IC to implement complete RF to baseband functionality compliant with the IEEE 802.11ad (WiGig) standard.

PRS4601 – 60 GHz BASEBAND IC

  • 802.11ad compliant PHY
    • Maximum data rate up to 4.62 Gb/s throughput
    • Single carrier MCS0 to MCS12 (16-QAM)
    • Variable rate LDPC FEC
    • Full support for Beamforming
  • USB 2.0/3.0 (5 Gb/s) device controller with integrated PHY
  • 802.11ad compliant MAC
    • Two integrated RISC CPUs
    • On-chip memory for all packet buffering, control and management functions
    • Contention-based and scheduled access with highly programmable scheduler
    • Configurable air propagation time
    • 128-bit AES security (GCMP)
    • Highly configurable peripheral interfaces
  • 8-client support
  • Antenna aiming feedback
  • Windows, Linux and Android support
  • 7mm x 7mm BGA

PRS1151 – 60 GHz PHASED ARRAY RADIO IC

  • 8 Tx/Rx antennas
  • Tx output power: 15 dBm (QPSK), 13 dBm (16-QAM)
  • Rx noise figure: 6 dB
  • PLL tunes to all channels of 802.11ad
  • Supports single carrier BPSK, π/2-BPSK, QPSK, π/2-QPSK, and 16-QAM
  • Integrated Tx and Rx antenna interfaces
  • Baseband I/Q interface
  • 3 / 4-wire SPI and 4 GPIOs for configuration and control
  • 8mm x 10mm BGA
Download Full Product Brief

Download X710 Chipset Product Brief:











The Peraso X715 Chipset

The Peraso X715 long range WiGig® phased array chipset is an 802.11ad compliant chipset targeted at fixed wireless broadband applications.

PRS4601 WiGig Baseband IC

  • IEEE 802.11ad compliant AP and STA with support for up to 64 clients
  • Fully integrated AFE, PHY and MAC
  • USB 3.0 interface
  • Highly flexible, dual CPU soft MAC integrates WiGig® MAC functions
  • PHY supports MCS0 to MCS12 (4.62 Gb/s)
  • Up to 3 Gb/s end-to-end throughput (MCS12)
  • Extensible API allows for fine control of performance and network operation
  • 7mm × 7mm BGA package

PRS1151 60 GHz phased array RFIC

• Support for 16 Tx/Rx antennas
• Tx output power (tiled operation): 20 dBm (QPSK), 13 dBm (16-QAM)
• Receiver noise figure: < 6 dB
• PLL tuning range: 57 to 66 GHz (6 channels at 1.08 GHz centers)
• Integrated 45 MHz crystal oscillator
• Power supplies: 1.2V, 1.8V, 2.5V
• Operating temperature: -40 °C to 85 °C • 8mm × 10mm BGA with 0.5mm pitch

Download Full Product Brief

Download X715 Chipset Product Brief:
